價格：人民幣11.5萬-12.6萬
| Performance | 1 | rated loading | 3000kg |
| 2 | overall weight | 9100-9600kg | |
| 3 | bucket capacity | 1.53-2.5m3 | |
| 4 | maximum tractionforce | 97KN | |
| 5 | maximumbreakout force | 120KN | |
| 6 | maximum grade ability | 30℃ | |
| 7 | maximum dump height | 3200mm | |
| 8 | maximum dump reach | 1006mm | |
| 9 | overall dimension (L×W×H) | 7200*2430*3070mm | |
| 10 | minimum turning radius | 5097mm | |
| Engine | 11 | model | WP6G125E332 |
| 12 | type | Common rail Guosan | |
| 13 | NO. of cylinder-bore*stroke | 6-108*125 | |
| 14 | rated power | 92kw—2200r/min | |
| 15 | maximum torque | 500N.m | |
| 16 | min. fuel-consume ratio | ≦210Kw h | |
| Transmission system | 17 | torque converter | YJ315-X |
| 18 | gearbox mode | Power shaft normally engaged straight gear | |
| 19 | gears | 4forward 2 reverse | |
| 20 | maximum speed | 39km/h | |
| Drive axles | 21 | ：main reducing spiral | bevel gear grade 1reduction |
| 22 | decelerating mode | Planetary reduction grade 1 | |
| 23 | wheel base (mm) | 2630mm | |
| 24 | wheel tread | 1200mm | |
| 25 | ground clearance | 400mm | |
| Hydraulic system | 26 | system working pressure | 16,5MPa |
| 27 | boom lifting time | 4.6 | |
| 28 | total time | 8.2±0.5s | |
| Brake system | 31 | service brake | air assist disc brake on 4 wheels |
| 32 | parking brake | Manual disk brake | |
| Tyre | 33 | type specification | 17.5-25 |
| 34 | front tyre pressure | 0.4Mpa | |
| 35 | rear tyre pressure | 0.35Mpa |
